Has anyone started a cross reference parts guide for the Murci?

Share this post


Link to post
Share on other sites
Has anyone started a cross reference parts guide for the Murci?





Yeah You .

Brake light switch 06 Murc egear

VW PN 3B0 945 511 D

Last summer , Sunday , 90 degrees , can't get into gear . Tested wires ( in a parking lot ) , jumped it with a paperclip , Monday , NO Lambo dealers around , gave PN to Audi parts , they referred me to VW parts , had 5 in stock 27 bucks , bought two .

Share this post


Link to post
Share on other sites

Bump, like to see this thread become a sticky!



Great do you mean Pinned ? as per the Diablo group?

Share this post


Link to post
Share on other sites

Power steering / lifting system fluid filter: Mercedes part # 000 466 21 04



Lamborghini parts catalog doesn't show it, but it's in the reservoir and should be changed with the fluid.

Share this post


Link to post
Share on other sites

LP640 Alternator Bosch 021 903 025 C



This cross references with a Euro VW van. BBB Industries and Wilson Electric are two of the largest OEM remanufacturers. BBB sells this reman unit directly to NAPA under Rayloc brand part number 213-8765 and it is $154.00 smile.gif))))) I checked it out and it is a perfect match and comes with 3yrs warranty. Sure as hell beats the $850 price from dealer. Hope this helps. I am also gonna add this to the cross reference thread.

Share this post


Link to post
Share on other sites

Murcielago /LP640 Front ABS / wheel speed sensor =£445 (680usd) from Lambo. No thanks!

I found a £40 (70usd) BMW E36 M3 rear abs sensor is a direct fit replacement, it just needs a bit of reflective heat insulation adding like the original.

Share this post


Link to post
Share on other sites
3rd brake light is common Hella light for BMW. 30 dollars on eBay.



Thanks but can you be more specific on the BMW model? I see tons of different 3rd brake lights for BMWs on eBay, but none look like a match.

Share this post


Link to post
Share on other sites
Yeah You .

Brake light switch 06 Murc egear

VW PN 3B0 945 511 D

Last summer , Sunday , 90 degrees , can't get into gear . Tested wires ( in a parking lot ) , jumped it with a paperclip , Monday , NO Lambo dealers around , gave PN to Audi parts , they referred me to VW parts , had 5 in stock 27 bucks , bought two .





Further update. The 511D part number above has now been superceded by 1K2 945 511 RDW. Still from the local VW dealer, 12GBP over this side of the pond. Same issue above, out one day, couldn't get gears at the lights.... pushed to side of road, and noticed no brake lights. New switch and back in the game. 3 minutes to change, start to finish, including making the tea !



If you look at the various VW forums, there have been lots of issues with the XXX511A-D switches, as they have an over complicated adjusting mechanism, and can be broken by incorrect installation procedure (for a brake light switch!). New switch looks quite different, connector and mounting is identical however.

Share this post


Link to post
Share on other sites

Murcielago 6.2





fuel pumps

Bosch part # 0580464048 or 69418. $97 on amazon.



Fuel Injectors

Accel 26 lbs./hr. Part # 150826 (set of 8) you can buy 2 sets for at around $300/set. (matches the original flow of the weber iw-31 270cc/min)





Fuel Pressure Regulators

I'll post part numbers once I know it works for sure.



Regards

Share this post


Link to post
Share on other sites
LP640 Alternator Bosch 021 903 025 C



This cross references with a Euro VW van. BBB Industries and Wilson Electric are two of the largest OEM remanufacturers. BBB sells this reman unit directly to NAPA under Rayloc brand part number 213-8765 and it is $154.00 smile.gif))))) I checked it out and it is a perfect match and comes with 3yrs warranty. Sure as hell beats the $850 price from dealer. Hope this helps. I am also gonna add this to the cross reference thread.





Further update, this cross reference alternator is also correct for the 6.2 Murci. To be exact, the alternator cross references with a 2000 VW Euro Van 2.8L with AC. It's a perfect fit with the correct output. Just about any auto parts store would be able to get one. I recommend the stores that will give you lifetime warranty.

Share this post


Link to post
Share on other sites

Thanks to member, "Digibeam"

If you need to get a cost effective climate system heater valve that is identical to the Lamborghini, I will mildly point you in the direction of Maserati, they have two such valves (left and right), one is the direct "plug in"replacement...

Right Heater Water Control TGK Valve 67635900 Maserati Quattroporte M139
